CommScope Era CAP M 9 - Mount the CAP M to a Wall or Vertical Surface; Mount a CAP M Using a Single Mounting Bracket

M0201AJB Era
™
Medium Power Carrier Access Point Installation Guide
© October 2018 CommScope, Inc. Page 25
Installing CAP Ms
Mount the CAP M to a Wall or Vertical Surface
TherearetwomountingoptionsfortheCAPM;followtheprocedurethatisappropriateforthisinstallation:
• "MountaCAPMUsingaSingleMountingBracket”onpage25
• "MountTwoCAPMsUsingaDualMountingBracket”onpage31.
Mount a CAP M Using a Single Mounting Bracket
1 ObtaintheCAPMSingleMountingBracket(CommScopePN7821955-xx).
2 Followthestepsin"UnpackandInspecttheCAPMandOptionalAccessories”onpage19.Table7liststhe
partsthatshipwiththeCAPMSingleMountingBracket.
3 Referto"DeterminetheMountingSite”onpage16todeterminethemountinglocation,whichmustbe
abletosupporttheweightanddimensionsoftheCAPM.
4 Referto"MountingOrientation”onpage24todeterminethemountingorientationoftheCAPM.
5 Refertoandobserveallcautionslistedin"GeneralMountingCautions”onpage23.
If this installation requires the optional Hybrid Fiber Splice Box to provide fiber and power to the CAP M,
follow the steps in
Table 7. Parts List for CommScope PN 7821955-XX
Description Quantity
Single Wall-Mounting Bracket
2
Installer must verify that the mounting surface will safely support the combined load of the electronic
equipment and all attached hardware and components.
