Era
™
Medium Power Carrier Access Point Installation Guide M0201AJB
Page 50 © October 2018 CommScope, Inc.
Installing CAP Ms
CAP M AC Power Cable
TheACpowercableisa3.2m(10.5ft)16AWGcablewitha4-pinAmphenolC016seriesplugononeendto
connecttotheCAP
MMainsconnector.Theotherendofthecableisunterminatedwith3endsplicesto
connecttotheACpowersource.A10m(33.7ft)ACpowercableisalsoavailableasanoption.TheACpower
cableisshownin
Figure9.
Figure 9. CAPMAC Power Cable
CAP M DC Power Cable
ThestandardCAPMDCpowercableisa3.2m(10.5ft)13AWGcablewitha4-pinAmphenolC016seriesplug
ononeendtoconnecttotheCAP
MMainsconnector.Theotherendofthecableisunterminatedwith2end
splicestoconnecttothe-48Vdcpowersource.ThestandardDCpowercableisshownin
Figure10.
Figure 10. CAPMDCPowerCable
Protecve
cap
1
2
3
4
CAP M
Mains
connector
Black
White
Green
Amphenol
4-Pin female
connector
3x
end splice
Protecve
cap
1
2
3
4
CAP M
Mains
connector
Black
Red
Amphenol
4-Pin female
connector
2x
end splice
