Installing CAP Ms
Determine the Power Consumption of the CAP M
UsethepowerconsumptionmatrixinTable5tocalculatepowerconsumptionforaCAPM,where
• theconsumptionnumbersareattheCAPMpowerinputsanddonotaccountforfeedlosses
• themaximumconsumptionnumbersinTable5donotincludethepowerconsumedbyanyattached
auxiliarydevices.BothCAPMpowerconsumptionandauxiliarydevicepowermustbeincludedwhen
calculatingfeedlosses.
Determine the Mounting Site
Whendecidingonasuitablemountingsite,observethefollowingrules;referalsoto"MountingOrientation”
onpage24.
• TheCAPMissuitableforinstallationindoorsoroutdoors.
• UsetheweightslistedinTable6todetermineasitethatcanbeartheweightoftheCAPMthatisbeing
installed,where:
– The“MaximumLiftWeight”isthehighestweightthatmustbeliftedduringinstallation.(Aninstaller
shouldlifttheCAP
Mcomponentsoneatatime,notawhollyconfiguredCAPM.)
– The“TotalHangingWeight”istheweightoftheCAPM,includingtheweightoftheMountingBracket,
minustheweightoftheexternalcablesandconnectors,thatthemountingsitemustbeableto
support.
• UsethedimensionsshowninFigure4onpage17forSingleMountandFigure5onpage18forDual
Mount.
Table 5. CAP M Power Consumption
Configuration Voltage Range (V) Typical Power (W) Maximum Power (W)
DC
1
36 - 60 Vdc 140 150
AC
1
100 - 264 Vac 140 150
1 Does not include SFP+ Module consumption. Can support up to 3W (more with engineering
consultation) maximum total SFP+ Module consumption. Typical installation (sufficient for SM up to
10km or MM) would be 0.8W typical, 1.0W max for each SFP+ Module.
Mains power must be interruptible with an external delay-actions mains breaker. For the Mains breaker,
observe the following recommendations.
• For the AC power supply, 120 Volt / 20 Amp max. or 240 Volt / 16 Amp, single-phase, 50 / 60 Hz AC
service is needed, i.e. the external AC breaker should be 20 Amps max. for 120-Volt service or 13 to
16 Amps for 240-Volt service.
• For the DC power supply, observe the local regulations of the DC service provider.
Table 6. Maximum CAP M Installation Weights
1
CAP M installed with this option …
Maximum Lift
Weight
Total Hanging
Weight
kg lbs. kg lbs.
Single Mounting Bracket (PN 7821954-xx) 19.2 42.3 20.5 45.2
Dual Mounting Bracket (PN 7821955-xx) 19.2 42.3 40 88.2
1 A Hybrid Fiber Splice Box (PN 7693816-xx) adds 0.3 kg (.66 lbs.) to the total
weights.
