Installing CAP Ms
Connect the CAP M Power
ConnectthePowerconnectorasappropriateforthisinstallation:
• "ConnecttheMainsPowertotheCAPM”onpage51
• "ConnectaHybridFiberSpliceBox”onpage52.
Connect the Mains Power to the CAP M
1 LocatetheMainspowercablethatwasdeliveredwiththeCAPM.
2 Locateorinstallasuitablepowerjunctionboxorreceptacleneartheunitandroutethepowercablefrom
thepowersourcetotheCAP
M.
3 Dependentonthetypeofpowersupplyusedbytheunit,wirethepowercabletothejunctionboxor
receptacle.Refertothecolorcodeandpinnumbersshownin:
• Figure9onpage50fortheACpowercable
• Figure10onpage50fortheDCpowercable.
4 Withthecable'sMainsplugdisconnectedfromtheCAPM,turnthecircuitbreakeron,unscrewtheplug's
protectivecover,andcarefullytesttheplugwithavoltmetertoensurethatthevoltageandpolarityare
correct.
5 Oncethetestinghasbeencompleted,turnoffthecircuitbreaker.
6 UnscrewtheprotectivecoverfromtheMainsconnectoroftheunit.
Do not connect or disconnect the power cable at the Mains connector while power is on. Turn off Mains
power before connecting the power cable at the unit, then, engage mains power again.
Do not connect the cable to the unit's Mains connector at this time. The power source must be
interruptible.
The Mains cable must be properly secured observing local regulations and electrical codes. Be sure to
allow enough slack in the cable at the CAP M to plug or unplug the cable into the Mains connector.
