CommScope Era CAP M 9 - Mount the CAP M to a 4 to 18 Pole

M0201AJB Era
™
Medium Power Carrier Access Point Installation Guide
© October 2018 CommScope, Inc. Page 39
Installing CAP Ms
Mount the CAP M to a 4" to 18" Pole
ThisprocedureisspecifictotheCAPMPoleMountingKitforUpto18"Poles(CommScopePN7692096-XX),
whichisusedwhenmountingaCAP
Mtoapolewithacircumferenceof4"to18"(10.2cmto45.8cm).
Figure8showstheassembledkitmountedtoapole.
Figure 8. Installation Views of the CAP M Pole Mounting Kit for Up to 18" Poles (CommScope PN 7692096-XX)
DothefollowingtoassembletheCAPMPoleMountingKitforUpto18"Poles,mountthekittoapole,and
thenmounttheCAP
Monthemountingkit.
1 ObtaintheCAPMPoleMountingKitforUpto18"Poles(CommScopePN7692096-XX).
2 ObtaineitheraSingleMountingBracketKit(CommScopePN7821955-xx)oraDualMountingBracketKit
(CommScopePN7821954-xx),asrequiredforthisinstallation.
This procedure requires two installers.
Back View
Side View
Front View
Bracket
Pole-Mounng
Bracket
Bracket
Threaded
Bolt
4" to 18"
(10.2 cm to 45.8 cm)
CAP M
Dual-Mounng
Bracket
CAP M
Dual-Mounng
Bracket
Brackets
Pole-Mounng Brackets
