Medium Power Carrier Access Point Installation Guide M0201AJB
Page 38 © October 2018 CommScope, Inc.
Installing CAP Ms
17 OnlowerrightoftheCAPM-2,reinstalltheM6x12screwanditswashersthatyouremovedinStep13on
page36.
a SlidefirsttheM6split-lockwasherandthentheM6plainwasherovertheM6x12screw.
b InserttheM6x12screwthroughthescrewholeshownbelow,andscrewitbackintotheCAPM
chassis;torqueto11N-m.
18 RepeatStep11ontheleftsideofCAPM-2.
19 Dooneofthefollowing:
• IfthisinstallationrequiresaHybridFiberSpliceBox,goto"AttachaHybridFiberSpliceBoxtothe
CAPM”onpage42.
• IfthisinstallationdoesnotaHybridFiberSpliceBox,goto"GroundingtheCAPM”onpage46.
M6x12 screw and
washer set in hole
furthest from the
mounng surface
