Installing CAP Ms
13 FrombothsidesofCAPM-2:
a LoosentheM6pins,leavingitswasherinplace.
b RemovethetwoM6screwsandtheirwashers;reservethescrewsandwashersasyouwilllater
reinstallthem.
Loosen the M6 pin
Remove the M6 screw
and its washer
