10.4 Mounting location
Mount the Condair CDA or CDA-S in the supply air duct at least 3 meters downstream from the nearest
fan and coil and with a minimum distance of 5x the humidication distance to the steam distributor (see
manual of the humidier).
10.5 Installation
1. At the place of location drill a hole with a diameter of 16 mm (0.63") as well as 2 holes for the self
tapping screws into the duct.
2. Loosen the two screws on the housing cover and remove cover.
3. Lead connecting cable through the cable gland and connect wires to the terminals according to the
wiring diagram. Reattach the housing cover and secure it with the two screws.
4. Align the duct ange concentrically with the hole and fasten it to the duct with the self-tapping screws.
5. Push the sensor probe of the Condair CDA or CDA-S through the duct ange into the duct. Determine
the insertion depth and x it with the screw in the duct ange.
Important: The measuring opening in the protective tube must point in the direction of air ow.
