69Condair RCC and RCC-NA
5.4 Mounting location
Mount the humidity controller Condair RCC or RCC-NA in a protected and easy accessible place at
least 1.5 m above the oor to the wall (mounting on ush-mounting or surface-mounting box). Observe
the following placement notes:
– Do not place the Condair RCC or RCC-NA in niches, behind curtains, etc.
– Do not place the Condair RCC or RCC-NA near heat sources, within the area with direct air draft or
direct sunlight.
5.5 Installation
1. Open the screw of the housing and remove mounting plate with the connecting unit.
2. Connect wires of the connection cable to the terminals according to the wiring diagram.
3. At the place of location x mounting plate (plastic screw facing downwards) with two screws to the
ush-mounting or wall-mounting box (see dimensional drawing).
4. Carefully snap housing onto the mounting plate, and x it with the screw (do not tighten screw too
much).
