Condair UDC - Wiring Diagrams;Configuration

59Condair DCC and DCC-NA
4.7 Wiring diagrams/Conguration
4.7.2.1 Wiring diagram/Conguration Condair DCC
0V / GND
1
1 2 3 4 5 6 7 8
24V
2 3 4 5
AO1
6
UI1
7
UI2
8
DCC
CDC
24V AC/DC
1
0V / GND
2
H OUT
3
STATUS
LED
JP1 JP3
Jumper Placement
24 V AC/DC ±10%
0V / GND
0...10 VDC/0...20 mA
0V / GND
0...10V 0...20mA
RT or Dry-Contact
UI2
0...10V 0...20mA 0...10V 0...20mA
RT or Dry-Contact
AO
UI1
