58 Condair DCC and DCC-NA
4.6.2 Dimensions
4.6.2.1 Dimensions Condair DCC
88 (3.5)60 (2.3) 14 (0.6)
88 (3.5)
16 (0.6)
58 (2.3)
44 (1.7)
32 (1.2)
50 (2.0)
0V / GND
1
1 2 3 4 5 6 7 8
24V
2 3 4 5
AO1
6
UI1
7
UI2
8
Dimensions in mm (inches)
4.6.2.2 Dimensions Condair DCC-NA
0V / GND
1
1 2 3 4 5 6 7 8
24V
2
N/A
3
N/A
4
N/A
5
AO 2-10V
6
Ext. Series In
7
Temp. Reset
8
73 (2.9)58 (2.3)
16(0.6)32 (1.2)
113 (4.5)
83 (3.25)
± 5 (0.2)
15 (0.6)
58 (2.3)
50 (2.0)
Dimensions in mm (inches)
