5.7 Wiring diagrams/Conguration
5.7.2.1 Wiring diagram/Conguration RCC
0V / GND
1
1 2 3 4 5 6 7 8
24V
2 3 4 5
AO1
6
UI1
7
UI2
8
RCC
Jumper Placement
24 V AC/DC ±10%
0V / GND
0...10 VDC/0...20 mA
0V / GND
0...10V 0...20mA
RT or Dry-Contact
UI2
0...10V 0...20mA 0...10V 0...20mA
RT or Dry-Contact
AO
UI1
5.7.2.2 Wiring diagram Condair RCC-NA
GND / 0V
1 2 3 4 5 6 7 8
1 2 3 4 5 6 7 8
24V N/A N/A N/A AO 2-10V N/A Temp. Reset
RH OUT
24 V AC/DC ±10%
0V / GND
