19Condair CDC, CDC-NA, CDC-ST and CDC-SL
2.4 Mounting location
The Condair CDC, Condair CDC-ST or Condair CDC-SL is installed directly on the duct.
– Mounting in the extract air duct (recommended):
Mount the CDC, Condair CDC-ST or Condair CDC-SL in the extract air duct close to the air outlet
of the room but downstream from a extract air fan if one is present.
– Mounting in the supply air duct:
Mount the CDC, Condair CDC-ST or Condair CDC-SL in the supply air duct at least 3 meters down-
stream from the nearest fan and coil and with a minimum distance of 5x the humidication distance
to the steam distributor (see manual of the humidier).
2.5 Installation
1. At the place of location drill a hole with a diameter of 16 mm (5/8") as well as 4 holes for the self
tapping screws into the duct.
2. Loosen the screw on the housing cover and open cover.
3. Lead connecting cable through the cable gland and connect wires to the terminals according to the
wiring diagram.
4. Stick gasket on the sensor side centrally on the housing (self-adhesive).
5. Insert the probe into the hole in the duct, then x housing to the duct using the 4 self-tapping screws
provided.
6. Close cover and x it with the screw (do not tighten screw too much).
