Condair UDC - Delivery; Mounting Location; Installation

56 Condair DCC and DCC-NA
4.3 Delivery
The delivery includes:
– PI humidity controller Condair DCC or DCC-NA
– Humidity sensor Condair CDC or CDC-NA
– Cable gland
– Fixing material
– Surface-mounting box (CDC only)
– Installation manual
4.4 Mounting location
Humidity controller Condair DCC / DCC-NA
Install the humidity controller Condair DCC or DCC-NA in a protected and easy accessible place at least
1.5 m above the oor to the wall (mounting on ush-mounting or surface-mounting box)
Humidity sensor Condair CDC / CDC-NA
See Section 2.5.
4.5 Installation
Humidity controller Condair DCC / DCC-NA
1. Open the screw of the housing and remove mounting plate with the connecting unit.
2. Connect wires of the connection cables to the terminals according to the wiring diagram.
3. At the place of location x mounting plate (plastic screw facing downwards) with two screws to the
ush-mounting or surface-mounting box (see dimensional drawing).
4. Carefully snap housing onto the mounting plate, and x it with the screw (do not tighten screw too
much).
Humidity sensor Condair CDC / CDC-NA
See Section 2.5.
