Condair UDC - Mounting Location; Installation

96 Condair CHR and CHR-NA
7.4 Mounting location
Install the Condair CHR or CHR-NA in a protected and easy accessible place at least 1.5 m above the oor
to the wall (mounting on ush-mounting or wall-mounting box).Observe the following placement notes:
– Do not place the Condair CHR or CHR-NA in niches, behind curtains, etc.
– Do not place the Condair CHR or CHR-NA near heat sources, within the area with direct air draft or
direct sunlight.
7.5 Installation
1. Open the screw of the housing and remove mounting plate with the connecting unit.
2. Connect wires of the connection cable to the terminals according to the wiring diagram.
3. At the place of location x mounting plate (plastic screw facing downwards) with two screws to the
ush-mounting or wall-mounting box (see dimensional drawing).
4. Carefully snap housing onto the mounting plate, and x it with the screw (do not tighten screw too
much).
