140 Condair APS and APS-NA
11.6.2 Dimensions APS or APS-NA
80.5 (3.17)
53.4 (2.10)
ø6 (0.24)
26.7 (1.05)
PG11
ø81 (3.19)
~55 (2.17)
ø6 (0.24)
18 (0.71)
51 (2.01) 26 (1.02)
P2
P1
ø93 (3.66)
ø4.5 (0.18)
45°
Dimensions in mm (inches)
11.6.3 Wiring diagram APS or APS-NA
2
3
1
1
3
2
ΔP
SC
SC
