21Condair CDC, CDC-NA, CDC-ST and CDC-SL
Environment
Operation IEC 721-3-3
Climatic Conditions Class 3 K5
Temperature -40…70°C (-40…158°F)
Humidity <95 %rH not condensing
Transport and Storage IEC 721-3-2 and IEC 721-3-1
Climatic Conditions Class 3 K3 and Class 1 K3
Temperature -40…80°C (-40…176°F)
Humidity <95 %rH not condensing
Mechanical Conditions Class 2M2
Standards
CE compliant to EMC Norm 2014/30/EU, Low
Voltage Directive 2014/35/EU
EN 61 000-6-1/ EN 61 000-6-3
Automatic electrical control and regulating de-
vices for domestic use and similar applications
EN 60 730 –1
Degree of protection according to 60529 IP60
Protection class III (IEC 60536)
General
Housing material PC and ABS
Filter material PTFE coated 1μm pores
Weight CDC (including packaging) 270 g (9.5 oz)
2.6.2 Dimensions
2.6.2.1 Dimensions Condair CDC / CDC-NA
ø14 x 157
(ø0.55 x 6.2)
47 (1.9)
91 (3.6)
68 (2.7)
ø14 (0.6)
74.5 (2.9)
54 (2.1)
ø16 (0.62)
Dimensions in mm (inches)
2.6.2.2 Dimensions Condair CDC-ST / CDC-SL
Dimensions in mm (inches)
47 (1.9)
91 (3.6)
68 (2.7)
60 (2.4)
60 (2.4)
ø16 (5/8")
ø14 x 77
(ø0.55 x 3)
ø14 (0.6)
