98 Condair CHR and CHR-NA
7.6.2 Dimensions
7.6.2.1 Dimensions CHR
88 (3.5)60 (2.3) 14 (0.6)
88 (3.5)
16 (0.6)
58 (2.3)
44 (1.7)
32 (1.2)
50 (2.0)
0V / GND
1
1 2 3 4 5 6 7 8
24V AC/DC
2
DO1
3
DO1
4
DO2
5
DO2
6
RT
7
RT
8
Dimensions in mm (inches)
7.6.2.2 Dimensions CHR-NA
0V / GND
1
1 2 3 4 5 6 7 8
24V AC/DC
2
DO1
3
DO1
4
DO2
5
DO2
6
RT
7
RT
8
73 (2.9)58 (2.3)
16(0.6)32 (1.2)
113 (4.5)
83 (3.25)
± 5 (0.2)
15 (0.6)
58 (2.3)
50 (2.0)
Dimensions in mm (inches)
