1. Introduction
BX-220 User’s manual
1
1.
Introduction
About the Product
This product is a fanless computer for embedded applications. It features an Intel Atom processor E3845
chipset. Thanks to a quad-core CPU, simultaneous stable high-speed processing for four applications is
possible with four cores. This CPU also allows for computing power almost four times that of
conventional products in addition to three times the graphics performance, a significant improvement.
Moreover, power consumption has been significantly reduced, resulting in nearly double the power
efficiency compared with the previous generation's architecture.It combines sufficient performance and
low power consumption in a space-saving design that can be installed in spaces only 50-mm thick with
roughly the same area as a paperback book. This "resource-saving PC" helps you design more compact,
energy efficient equipment to reduce running costs and promote energy efficiency.
It has extension interfaces such as DVI-I, Display Port, 1000BASE-T, USB 3.0, and serial. It employs a
CFast card for storage and is fanless to ensure a totally spindleless design that simplifies maintenance.
In addition, this product is equipped with a proprietary extended RAS*1 function independent of the main
computer functions. This feature provides various functions to increase system reliability by
automatically restarting the system when detecting errors such as frozen programs, operating system
startup faults, and a rise in internal temperature, and by saving detailed logs of the occurrence of errors,
which can be useful in failure analysis.
Embedded-type CPU have been adopted. The use of readily available parts ensures the ease of the use of
the product. In addition, the use of Contec-customized BIOS allows support to be provided at the BIOS
level.
This product is available in the following 5 models:
- Base model with Intel Atom Processor E3845 1.91GHz
BX-220D-DC700000 (Memory 4GB, ECC, without OS, without CFast)
- OS-installed model with Intel Atom Processor E3845 1.91GHz
BX-220D-DC731211 (Memory 4GB, ECC, Windows Embedded Standard 7 32bit (Japanese version),
CFast Card (SLC) 16GB)
BX-220D-DC731212 (Memory 4GB, ECC, Windows Embedded Standard 7 32bit (English version),
CFast Card (SLC) 16GB)
BX-220D-DC761211 (Memory 4GB, ECC, Windows Embedded Standard 7 32bit (Japanese),
CFast Card (MLC) 32GB)
BX-220D-DC761212 (Memory 4GB, ECC, Windows Embedded Standard 7 32bit (English)
CFast Card (MLC) 32GB)
*1 Reliability Availability and Serviceability: Support functions for stable system operation.
