BX-220 User’s manual
H/W Monitor
View hardware monitor information such as the CPU temperature.
Aptio Setup Utility - Copyright (C) 20
xx American Megatrends, Inc.
Advanced
Pc Health Status
System temperature : +35 C
CPU temperature : +42 C
VCORE : +0.888 V
+1.8V : +1.760 V
+5V : +5.024 V
+5VSB : +5.056 V
+3.3
VSB
: +3.312 V
+3.3 VCC : +3.296 V
VBAT : +3.216 V
→←:Select Screen
↑↓:Select Item
Enter:Select
+/-:Change Opt.
F1:General Help
F2:Previous Values
F3:Optimized Defaults
F4:Save & Exit
ESC:Exit
Version x.xx.xxxx. Copyright (C) 20xx American Megatrends, Inc.
Figure 4.6. H/W Monitor (Actual Display May Vary.)
