BX-220 User’s manual
Super IO Configuration
Configure the operation settings for Super IO.
Aptio Setup Utility - Copyright (C) 20
xx American Megatrends, Inc.
Advanced
Super IO Configuration
Super IO Chip NCT6106D
▶ Serial Port A Configuration
▶ Serial Port B Configuration
▶ RS-485 Port Configuration
→←:Select Screen
↑↓:Select Item
Enter:Select
+/-:Change Opt.
F1:General Help
F2:Previous Values
F3:Optimized Defaults
F4:Save & Exit
ESC:Exit
Version x.xx.xxxx. Copyright (C) 20xx American Megatrends, Inc.
Figure 4.5. Super IO Configuration
Table 4.8. Super IO Configuration
Item
Option
Description
Serial Port A
Configuration
Refer to Table 4.9. -
Serial Port B
Configuration
Refer to Table 4.10. -
RS-485 Port
Configuration
Refer to Table 4.11. -
Table 4.9. Serial Port A Configuration
Item Option Description
Serial Port
Disabled
Enabled
Configure the operation settings for serial
port A.
Change Settings
IO=3F8h; IRQ=4;
IO=3F8h; IRQ=3,4,5,6,7,9,10,11,12;
IO=2F8h; IRQ=3,4,5,6,7,9,10,11,12;
IO=3E8h; IRQ=3,4,5,6,7,9,10,11,12;
IO=2F8h; IRQ=3,4,5,6,7,9,10,11,12;
Do not change this setting.
