4. BIOS Setup
44
BX-220 User’s manual
South Bridge Configuration
Configure the South Bridge settings.
Aptio Setup Utility - Copyright (C) 20xx American Megatrends, Inc.
Chipset
▶ Azalia HD Audio
▶ USB Configuration
High Precision Timer [Enabled]
Restore AC Power Loss [Power On]
Serial IRQ Mode [Quiet]
Onboard LAN A Controller [Enabled]
Onboard LAN B Controller [Enabled]
→←:Select Screen
↑↓:Select Item
Enter:Select
+/-:Change Opt.
F1:General Help
F2:Previous Values
F3:Optimized Defaults
F4:Save & Exit
ESC:Exit
Version x.xx.xxxx. Copyright (C) 20xx American Megatrends, Inc.
Figure 4.16. PCH-IO Configuration
Table 4.20. PCH-IO Configuration
Item
Option
Description
Azalia HD Audio
Refer to
Table 4.21.
-
USB Configuration
Refer to
Table 4.22.
-
High Precision Timer
Enabled
Disabled
Configure the high-precision event timer settings.
Restore AC Power Loss
Power Off
Power On
Last State
Set whether to start the system at the same time the power supply
starts.
Power OFF:
Press the power button to start the system. The system does not start
at the same time the power supply starts.
Power ON:
The system will start at the same time the power supply starts.
Last State:
If the power is turned off while the system is on, the system will start
the next time the power supply starts.
Serial IRQ Mode
Quiet
Continuous
Do not change this setting.
Onboard LAN A
Controller
Enabled
Disabled
Configure the LAN A Controller settings.
Onboard LAN B
Controller
Enabled
Disabled
Configure the LAN B Controller settings.
