SATA Configuration
Configure the SATA controller settings.
Aptio Setup Utility - Copyright (C) 20xx American Megatrends, Inc.
Advanced
SATA Configration
Serial-ATA (SATA) [Enabled]
SATA Test Mode [Disabled]
Select SATA Port/CFast Card [CFast Card]
SATA Speed Support [Gen2]
SATA ODD Port [No ODD]
SATA Mode [AHCI Mode]
Serial-ATA Port 0 [Enabled]
Serial-ATA Port 1 [Enabled]
SATA Port 0
xxxx
SATA Port 1
xxxx
→←:Select Screen
↑↓:Select Item
Enter:Select
+/-:Change Opt.
F1:General Help
F2:Previous Values
F3:Optimized Defaults
F4:Save & Exit
ESC:Exit
Version x.xx.xxxx. Copyright (C) 20xx American Megatrends, Inc.
Figure 4.9. SATA Configuration
Table 4.14.
SATA Configuration
Item
Option
Description
Serial-ATA (SATA)
Enabled
Disabled
Configure the SATA controller operation
settings. Changing this setting will cause the
CFast drive to become unrecognized.
SATA Test Mode
Enabled
Disabled
Do not change this setting.
Select SATA Port /
CFast Card
SATA Port
CFast Card
Do not change this setting.
SATA Speed Support
Gen1
Gen2
Do not change this setting.
SATA ODD Port
Port0 ODD
Port1 ODD
No ODD
Do not change this setting.
SATA Mode
IDE Mode
AHCI Mode
Specify the SATA device mode.
Changing this setting will require the OS to be
reinstalled.
Serial-ATA Port 0
Enabled
Disabled
Configure the operation settings for SATA
port0.
Serial-ATA Port 1
Enabled
Disabled
Configure the operation settings for SATA
port1.
