2. System Reference
BX-220 User’s manual
9
2.
System Reference
Specification
Table 2.1. Functional Specification < 1 / 2 >
Model BX-220D-DC7xxxxx
CPU Intel® Atom™ Processor E3845 1.91GHz
BIOS BIOS (mfd. by AMI)
Memory 4GB, 204pin SO-DIMM socket x 1, PC3-10600(DDR3L 1333) ECC
Graphic Intel® HD Graphics (built-in CPU)
System
resolution
Analog RGB 640x480, 800x600, 1,024x768, 1,152x864, 1,280x600, 1,280x720, 1,280x768,
1,280x800, 1,280x960, 1,280x1,024, 1,360x768, 1,366x768, 1,400x1,050, 1,440x900,
1,600x900, 1,680x1,050, 1,920x1,080, 1,920x1,200 (16,770,000 colors, ReduceBlanking)
DVI-D 640x480, 800x600, 1,024x768, 1,152x864, 1,280x600, 1,280x720, 1,280x768,
1,280x800, 1,280x960, 1,280x1,024, 1,360x768, 1,366x768, 1,400x1,050, 1,440x900,
1,600x900, 1,680x1,050, 1,920x1,080, 1,920x1,200 (16,770,000 colors, ReduceBlanking)
Display Port 640x480, 800x600, 1,024x768, 1,152x864, 1,280x600, 1,280x720, 1,280x768,
1,280x800, 1,280x960, 1,280x1,024, 1,360x768, 1,366x768, 1,400x1,050, 1,440x900,
1,600x900, 1,680x1,050, 1,920x1,080, 1,920x1,200 (16,770,000 colors, ReduceBlanking)
Audio HD Audio compliant, LINE OUT x 1, MIC IN x 1
CFast card slot 2 slot, CFast CARD Type I x 2 bootable
BX-220D-DC73121x: Built-in CFast card slot (SLC) (16GB, 1 partition) *1
BX-220D-DC76121x: Built-in CFast card slot (MLC) (32GB, 1 partition) *1
Other models: none
LAN *2 Intel I210IT Controller
1000BASE-T/100BASE-TX/10BASE-T 2 port (Wake On LAN support)
USB USB 3.0 compliant 1 port
USB 2.0 compliant 2 port
Serial I/F RS-232C (general-purpose) : 2port (SERIAL PORTA, B), 9pin D-SUB connector (male)
Baud rate : 50 - 115,200bps
RS-422/485 (general-purpose) 1port, Baud rate : 50 - 115,200bps
RAS WDT: Software programmable, 1sec - 255sec (Time up allows reset, interrupt, or external
output)
Remote reset: Input signal from external device
General-purpose I/O Photocoupler insulation inputs/outputs (3 of each)
(One output used for WDT external output, one input switched between remote reset or
remote power on.)
Hardware monitoring Monitoring CPU temperature, power voltage
RTC/CMOS Lithium backup battery life: 10 years or more.
The real-time clock is accurate within ±3 minutes (at 25°C) per month
Power Management Power management setup via BIOS, Power On by Ring / Wake On LAN,
Supports PC98/PC99 ACPI Power management
*1: The capacity of CFast is a value when 1GB is calculated by 1 billion bytes. The capacity that can be recognized from
OS might be displayed fewer than an actual value.
