2. System Reference
10
BX-220 User’s manual
Table 2.1. Functional Specification < 2 / 2 >
Model
BX-220D-DC7xxxxx
Interface
Display
DVI-I x 1 (29pin DVI-I connector), Display Port x1
Audio LINE OUT : 3.5φ Stereo mini jack, Full-scale output level 1.4Vrms(Typ.)
MIC IN : 3.5φ Stereo mini jack, Full-scale input level 1.4Vrms(Typ.)
CFast card slot 2 slot, CFast CARD Type I x 2, bootable
BX-220D-DC700000 : -,
BX-220D-DC73121x : Built-in CFast card slot contains a CFast card(SLC) .
(16GB, 1 partition)*1
BX-220D-DC76121x : Built-in CFast card slot contains a CFast card(MLC) .
(32GB, 1 partition)*1
LAN *2 2 port (RJ-45 connector)
USB USB3.0 compliant 1port (TYPE-A connector x1)
USB2.0 compliant 1port (TYPE-A connector x2)
RS-232C
2 port (9pin D-SUB connector [male])
RS-422/485/
General-purpose I/O /
RAS
1 port (15pin D-SUB connector [femaie])
Power supply
Rated input voltage 12 - 24VDC *3
Range of input
voltage
10.8 - 31.2VDC
Power consumption 12V 2.6A, 24V 1.5A
External device power
supply capacity
CFast card slot : 3.3V : 1A(500mAx2)
USB3.0 I/F : +5V : 0.9A (900mAx1)
USB2.0 I/F : +5V : 1A (500mAx2)
Physical dimensions
(mm)
178 (W) x 115(D) x 29(H) (No protrusions)
Weight
About 0.8kg (Excluding attachment fittings)
*2: If you use the 1000BASE-T, be careful of the operating temperature.
For more details on this, refer to chapter3, Installation Requirements.
*3: Use a power cable shorter than 3m.
