3. Hardware Setup
20
BX-220 User’s manual
Installation Requirements
There are limits to the ambient temperature range depending on the installation orientation.
Be sure that the operating temperature is within the range specified in the installation environment
requirement by making space between the product and device that generates heat or exhaust air.
Installable directions at operating temperature 0 - +50
°
C: (1), (2), (3), (4), (5), (8)
(When using 1000BASE-T: 0 - 45
°
C)
Installable directions at operating temperature 0 - 45
°
C (6), (7)
(When using 1000BASE-T: 0 - 40
°
C)
Figure 3.7. Installation Orientation
Note that even though the ambient temperature is within the specified range, an operational
malfunction may occur if there is other device generating high heat; the radiation will influence the
product to increase its temperature.
