3. Hardware Setup
User’s Manual
25
Distances between the BOX-PC and Its Vicinity
100mm or more (above)
50mm or more (side)
50mm or more (side)
50mm or more (back)
Connectors
Figure 3.11. Distances between the BOX-PC and Its Vicinity
