3. Hardware Setup
User’s Manual
21
(4) Close the top cover and secure it with screws.
Figure 3.4. Installing the Hard Disk
Installing the Main Memory (DIMM)
Compatible DIMM Types
Obtain the following special option products.
- Package type : 144-pin, small outline DIMM
- Specifications : 3.3V, PC100/CL2
- Capacity : 64MB / 128MB
- Type : SDRAM
- Optional memories * : 64MB : PC-MSD64-144H
128MB : PC-MSD128-144H
* Operation is not guaranteed if memory parts other than CONTEC
option products are used.
Main Memory (DIMM) Installation Procedure
Follow the next steps to fit the memory into the DIMM socket:
To Next Page
