I/O Port Addresses
Table 6.1. I/O Port Addresses
000-00F DMA controller 1 (slave) ch0-3 (8-bit transfer)
010-01F Reserved for system
020-03F Interrupt controller 1 (master)
040-05F Timer
060-06F Keyboard controller
070-07F RTC, NMI mask
080-09F DMA page register
0A0-0BF Interrupt controller 2 (slave)
0C0-0DF DMA controller 2 (master) ch5-7 (16-bit transfer)
0E0-0FF Reserved for system
100-12F Available to user Available to expansion bus (CP and C4P models)
140-16F Available to user Available to expansion bus (CP and C4P models)
170-17F IDE hard disk controller Secondary
180-18F Reserved for system
190-1DF Available to user Available to expansion bus (CP and C4P models)
1E8-1EF Reserved for system
1F0-1FF IDE hard disk controller Primary
200-277 Available to user Available to expansion bus (CP and C4P models)
278-27F Reserved for parallel port LPT2
280-2E7 Available to user Available to expansion bus (CP and C4P models)
2E8-2EF Reserved for serial port COM4
2F0-2F7 Available to user Available to expansion bus (CP and C4P models)
2F8-2EF Serial port COM2
300-35F Available to user Available to expansion bus (CP and C4P models)
370-375 Reserved for system
376-377 IDE hard disk controller Secondary
378-3AF Reserved for parallel port LPT1
3B0-3BB Reserved for system
3BC-3BF Reserved for parallel port LPT3
3C0-3DF Reserved for system
3E0-3E7 PCMCIA C, CP and C4P models
3E8-3EF Serial port COM3 (Touch panel, Default factory setting)
3F0-3F7 FD controller
3F8-3FF Serial port COM1
4D0-4DF Reserved for system
CF0-CFF Reserved for system
4000-4007 RAS functions
4008-400F Reserved for system
46E8 Reserved for system
83D0-B3D3 Reserved for system
