Helix Operator’s Manual
© 2012-2014,Cornelius Inc. All Rights Reserved - 7 - Publication Number: 621058497OPR
SPECIFICATIONS
Line Voltage: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .230VAC, 50 Hz
Max. Current Draw: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12 Amps
Water Inlet Size:. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3/8 in. (.95 cm) I.D.
Water Supply Pressure . . . . . . . . . . . . . . . . . . . . . . . 0.48-0.83 MPa (70-120 psig)
Drain Outlet Size:. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.665 in. (4.23 cm) I.D.
Clearance Requirements: . . . . . . . . . . 12 in. (30.48 cm) top; 2 in. (5.08 cm) back
Equipment Weight: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 612 lbs (278 kg)
CO
2/compressed air Tubing Size: . . . . . . . . . . . . . . . . . . . . 1/4 in. (0.635 cm) I.D.
CO
2/compressed air Supply Pressure: . . . . . . . . . . . 0.48-0.83 MPa (70-120 psig)
BIB Tray Size: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 gal. (7.6 liters)
Ice Storage Capacity: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18 lbs (14.5 kg)
Ice Make Rate:. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 600 lb/day (272 kg/day)
Unit Height: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75 in. (190.5 cm)
Unit Width: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26 in. (66.04 cm)
Unit Depth:. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34 in. (86.36 cm)
Ambient Operating Temperature:. . . . . . . . . . . . . . . . . . 55 to 95
o
F (12.8 to 35°C)
A-Weighted Sound Pressure Level (during blender operation) . . . . . . . . . . <70dB
The Helix unit is capable of using syrups with particulate matter up to 1/8” in size.
