You can set camera BLC mode.
⚫ Self-adaptive: In the backlight environment, the system can
automatically adjust image brightness to clearly display the
object.
⚫ BLC:
◇ Default: The device auto exposures according to the
environment’s situation so that the darkest area of the video
is cleared
◇ Customize: After select the specified zone, the system can
expose the specific zone so that the zone can reach the
proper brightness.
⚫ WDR: In backlight environment, it can lower the high bright
section and enhance the brightness of the low bright section. So
that you can view these two sections clearly at the same time.
⚫ HLC: In the backlight environment, it can lower the brightness of
the brightest section and reduce the area of the halo and lower
the brightness of the whole video.
⚫ Stop: It is to disable the BLC function.
⚫ You can set camera WB mode. It can affect the image whole hue
so that the image can accurately displays the environment status.
⚫
⚫ Different cameras support different WB modes such as auto,
manual, natural light, outdoor etc.
Configure the color and black & white mode of the image. This
setting is not affected by the configuration files. The default setting is
Auto.
⚫ Color: The camera outputs color image only.
⚫ Auto: Depends on the camera, such as overall brightness and
whether there is an IR light, either color image or black & white
image is output.
⚫ B/W: The camera outputs Black and white image only.
⚫ Sensor: It is to set when there is peripheral connected IR light.
The Sensor item is for some non-IR device only.
Step 3 Click Apply.
1.2.5 Encode
⚫ You can set video bit stream and image parameters.
1.2.5.1 Encode
⚫ You can set video bit stream parameters such as bit stream type, compression, resolution.
⚫ Some series products support three streams: main stream, sub stream 1, sub stream 2. The sub stream
maximally supports 1080P.
Step 1 Select Main menu > CAMERA > ENCODE > ENCODE.
The ENCODE interface is displayed. See Figure 1-55.
