Step 2 Hang the inverter onto the mounting bracket as shown in
Figure 3-9 and Figure 3-10:
(a) Lift mounting: Locate the lifting eyes at the top of the
inverter. Use sling rope or bar (inserted through both lifting
eye nuts) to lift the inverter onto the bracket. The minimum
angle between the two sling ropes should be less than 90
degrees.
(b) Manual mounting: Two people are required to safely lift the
inverter by the grab handle positions marked in Figure
3-10 and mount it onto the bracket.
CAUTION:
The main enclosure of the CPS SCA50KTL-DO/US-480 and
SCA60KTL-DO/US-480 3-Phase String Inverters is approx 56kg
(123.5 pounds).
Ensure the mounting bracket is properly installed
and secured before hanging the inverter on the bracket. It is
recommended to have at least 2 people to mount the inverter due
to the weight of the equipment.
