Crestron TST-902 User Manual

22 • TST-902 Product Manual — Doc. 7750C
TST-902-DS Specifications
Product specifications for the TST-902-DS are provided below.
Product Specifications
Connectors
Power (1) Attached 6ft (1.83m) cable with inline 1.7 x 4.0mm DCpower connector;
24VDC power input (for included power pack)
Power
Power Pack (Included) Input:0.6A (maximum) @100–240VAC, 50/60Hz;
Output:0.75A@ 24VDC;
DC power connection can be made via charging dock or onboard DCpower
connector;
Includes 6ft (1.83m)attached cable with 1.7 x 4.0mm DCpower barrel
connector and universal blade kit to accommodate most ACoutlet types
Power Consumption 7W
Environmental
Temperature 32° to 112°F (0° to 45°C);
50° to 104°F (10° to 40°C) while charging
Humidity 10% to 90% RH (noncondensing)
Construction
Metal, black
Dimensions
Height 5.14in. (131mm);
6.82in. (174mm) with touch screen docked
Width 6.66in. (170mm);
10.37in. (264mm) with touch screen docked
Depth 5.08in. (129mm);
5.25in. (134mm) with touch screen docked
Weight
37oz (1049g)
Compliance
CE
To search for product certificates, refer to support.crestron.com/app/certificates.

Crestron TST-902 Specifications

General

Color depth	24 bit
Display type	TFT
Backlight type	LED
Contrast ratio	700:1
Display diagonal	8.7 \
Display brightness	300 cd/m²
Display resolution	1008 x 588 pixels
Touchscreen technology	Projected capacitive system
Audio formats supported	MP3
Wi-Fi	-
Product color	Black
Internal memory	1000 MB
Operating temperature (T-T)	0 - 45 °C
Operating relative humidity (H-H)	10 - 90 %
Power supply location	External
AC adapter output voltage	24 V
Power consumption (typical)	7 W

Weight and Dimensions

Depth	19 mm
Width	264 mm
Height	164 mm
Weight	808 g
