Crestron TST-902 - TST-902-DSW-PMK Installation; In the Box; Install the Mounting Kit

60 • TST-902 Product Manual — Doc. 7750C
TST-902-DSW-PMK Installation
Use the following procedures to install the TST-902-DSW-PMK.
NOTE:The TST-902-DSW-PMK preconstruction mounting kit is a TST-902-DSWmounting
accessory that is designed for preconstruction applications where mounting hardware
(without a back box) will be fastened to the left or right-hand stud of a framed wall prior to
drywall installation.
In the Box
Qty. Description
1 TST-902-DSW-PMK, Preconstruction Mounting Kit for TST-902-DSW
Additional Items
1 Wire Jumper, Black (2007838)
4 Screw, 6-32 x 1-1/2in., Pan Head,Phillips (2007254)
1 Cover Plate, Metal (2042716)
Install the Mounting Kit
To install the TST-902-DSW-PMKpreconstruction mounting kit:
NOTES:
l
Ensure the chosen mounting location allows for an air gap of at least 12in. (305mm)
in the wall cavity above and below the TST-902-DSW for heat dissipation.
l
The wire jumper is intended to hang wires during installation to keep them away from
any cutting tools and should be secured in the mounting bracket as described in the
following procedure.
l
If the mounting bracket will not be installed onto a wooden stud, consider the specific
requirements for the installation. For example, installation onto steel studs will require
a different type of screw than installation onto wooden studs.
1. Position the TST-902-DSW-PMK mounting bracket against the front edge of the stud.
Ensure the extended edge of the mounting bracket is aligned with the front edge of the
stud.
