66 • TST-902 Product Manual — Doc. 7750C
TST-902-DSW-WMKM Installation
Use the following procedures to install the TST-902-DSW-WMKM.
NOTE:The TST-902-DSW-WMKM postconstruction wall mount kit is a
TST-902-DSWmounting accessory that is designed for postconstruction applications where
mounting hardware will be installed in an existing framed wall or similar flat surface using a
mud ring.
In the Box
Qty. Description
1 TST-902-DSW-WMKM, Postconstruction Wall Mount Kit for TST-902-DSW
Additional Items
1 Mounting Plate, Metal, 12.00 x 8.80in. (2045235)
2 Adjustment Plate, Metal (2028255)
4 Fastener, U-Type (2004121)
1 Template, Cutout (4523568)
1 Mud Ring, Metal, 12.56 x 8.61in. (2045233)
4 Screw, 6-32 x 1-1/2in., Flat Head, Phillips (2031703)
Prepare for Installation
The following materials (not included)are required to install the
TST-902-DSW-WMKMpostconstruction mounting kit.
l
Drywall saw (or equivalent)
l
Level
l
Drywall screws (4)
l
#2 Phillips screwdriver
l
Tools and materials for applying a drywall joint compound
Additionally, a cutout template is provided with the TST-902-DSW-WMKM that can be used
when making the drywall cutout for the mounting hardware. The dimensions for the cutout
template are provided below as a reference (not to scale).
