36 • TST-902 Product Manual — Doc. 7750C
TST-902 Installation
Use the following procedures to install the TST-902.
In the Box
Qty. Description
1 TST-902, 8.7in. Wireless Touch Screen
Additional Items
1 Battery Pack, Rechargeable, TST-902-BTP(4513771)
1 Docking Station, TST-902-DS (4517187)
1 Power Cord, 6ft, 7in. (2.0m)(2001134)
1 Power Supply, 24VDC @0.75A, 100–240VAC(2048337)
1 Tool, T-Pin (2020478)
Install the Battery Pack
The TST-902 ships with a rechargeable battery pack (TST-902-BTP)that must be installed into
the touch screen prior to use.
CAUTION:Note the following to avoid damage to the TST-902 or its battery pack:
l
The TST-902 is sensitive to electrostatic discharge (ESD). To avoid damage to the
device, install the battery pack while wearing a grounding strap or while working
within a grounded workstation.
l
To prevent damage to the multipin connector and wiring, handle the battery pack with
care during installation.
l
The battery pack is enclosed in a black plastic overwrap that is designed to stay on the
battery pack permanently. It must not be removed.
To install the battery pack into the TST-902:
1. Insert the provided t-pin tool into one of the two tab release holes on the rear of the
TST-902, and then slide the bottom cover downward to release the tab on that side.
2. Repeat step 1 for the other tab release hole.
