Crestron TST-902 - TST-902-DSW Wall Dock Specifications

24 • TST-902 Product Manual — Doc. 7750C
TST-902-DSW Specifications
Product specifications for the TST-902-DSW are provided below.
Product Specifications
Connectors
24VDC (1) 2-pin 3.5mm detachable terminal block;
24VDCpower input;
Wire size:18AWG (0.75mm
2
) maximum
Controls
OPEN (1) Push button, accessible when touch screen is not docked;
Releases the docking mechanism that allows the TST-902 to be docked
Power Requirements
Cresnet® Power Usage 11W(0.46A@ 24VDC) with touch screen docked
NOTE:May be powered by Cresnet network power or a dedicated Cresnet power supply. Does not
support Cresnet data communication (only power).
Environmental
Temperature 41° to 112°F (5° to 45°C);
50° to 104°F (10° to 40°C) while charging
Humidity 10% to 90% RH (noncondensing)
Heat Dissipation 38BTU/hr (with touch screen docked)
Enclosure
Chassis Metal, flush-mountable in a vertical wall structure (with optional mounting
accessories, sold separately)
1
Dimensions
Height 8.02in. (204mm)
Width 11.86in. (302mm)
Depth 3.20in. (82mm);
3.25in. (83mm) total depth when touch screen is docked
Weight
5.0lb (2.3kg)
Compliance
