Crestron TST-902 - TST-902-BTP Battery Pack Installation

40 • TST-902 Product Manual — Doc. 7750C
TST-902-BTP Installation
Use the following procedures to install the TST-902-BTP.
NOTE:One TST-902-BTPis included with the TST-902 touch screen. Additional
TST-902-BTPbattery packs can be purchased as replacements.
In the Box
Qty. Description
1 TST-902-BTP, Battery Pack for TST-902
Additional Items
1 Tool, T-Pin (2020478)
Remove the Existing Battery Pack
The TST-902 battery pack should be replaced every 18 to 24 months under normal usage. The
TST-902-BTP installs in place of the existing battery pack.
CAUTION:Note the following to avoid damage to the TST-902-BTPor the touch screen:
l
The TST-902 touch screen is sensitive to electrostatic discharge (ESD). To avoid
damage to the device, install the TST-902-BTP while wearing a grounding strap or
while working within a grounded workstation.
l
To prevent damage to the multipin connector and wiring, handle the TST-902-BTP
with care during installation.
l
The TST-902-BTP is enclosed in a black plastic overwrap that is designed to stay on
the battery pack permanently. It must not be removed.
To remove a battery pack from the TST-902 touch screen:
1. Insert the provided t-pin tool into one of the two tab release holes on the rear of the touch
screen, and then slide the bottom cover downward to release the tab on that side.
2. Repeat step 1 for the other tab release hole.
