76 • TST-902 Product Manual — Doc. 7750C
TST-902-DSW-WMKT Installation
Use the following procedures to install the TST-902-DSW-WMKT.
NOTE:The TST-902-DSW-WMKT postconstruction wall mount kit is a
TST-902-DSWmounting accessory that is designed for postconstruction applications where
mounting hardware will be installed in an existing framed wall or similar flat surface using a
mud ring.
In the Box
Qty. Description
1 TST-902-DSW-WMKT, Postconstruction Wall Mount Kit for TST-902-DSW
Additional Items
1 Mounting Plate, Metal, 12.00 x 8.80in. (2045235)
1 Template, Cutout (4523568)
1 Trim Ring, Metal, 11.30 x 7.40in. (2045234)
4 Screw, 6-32 x 1-1/2in., Flat Head, Phillips (2031703)
Prepare for Installation
The following materials (not included)are required to install the
TST-902-DSW-WMKTpostconstruction mounting kit.
l
Drywall saw (or equivalent)
l
Level
Additionally, a cutout template is provided with the TST-902-DSW-WMKT that can be used
when making the drywall cutout for the mounting hardware. The dimensions for the cutout
template are provided below as a reference (not to scale).
