Crestron TST-902 User Manual

In the Box 36
Install the Battery Pack 36
Place the TST-902 39
TST-902-BTP Installation 40
In the Box 40
Remove the Existing Battery Pack 40
Install the TST-902-BTP 42
Charge the TST-902-BTP 42
Store the TST-902-BTP 43
Recycle the TST-902-BTP 43
TST-902-DS Installation 44
In the Box 44
Install the TST-902-DS 44
TST-902-DSW Installation 46
In the Box 46
Install the Mounting Hardware 46
Install the TST-902-DSW 47
Dock the Touch Screen 50
Undock the Touch Screen 50
TST-902-DSW-BB Installation 53
In the Box 53
Install the Back Box 53
TST-902-DSW-BBI Installation 58
In the Box 58
Install the Back Box 58
TST-902-DSW-PMK Installation 60
In the Box 60
Install the Mounting Kit 60
TST-902-DSW-WMKM Installation 66
In the Box 66
Prepare for Installation 66
Install the Mounting Kit 67
TST-902-DSW-WMKT Installation 76
In the Box 76
Prepare for Installation 76
Install the Mounting Kit 77
Configuration 82
Initial Setup 83
Access the Setup Screens 83
Set Up an Extended Range RFConnection 83
Set Up a Wi-Fi Network Connection 85
Upgrade Firmware 89
Local Configuration 90
iv • Contents Product Manual — Doc. 7750C

Crestron TST-902 Specifications

General

Color depth	24 bit
Display type	TFT
Backlight type	LED
Contrast ratio	700:1
Display diagonal	8.7 \
Display brightness	300 cd/m²
Display resolution	1008 x 588 pixels
Touchscreen technology	Projected capacitive system
Audio formats supported	MP3
Wi-Fi	-
Product color	Black
Internal memory	1000 MB
Operating temperature (T-T)	0 - 45 °C
Operating relative humidity (H-H)	10 - 90 %
Power supply location	External
AC adapter output voltage	24 V
Power consumption (typical)	7 W

Weight and Dimensions

Depth	19 mm
Width	264 mm
Height	164 mm
Weight	808 g
