Product Manual Doc. 7750C TST-902 71
7. Route the combined mounting plate and adjustment plate assembly though the mud ring
and drywall cutout carefully, and then rest the assembly against the interior surface of the
drywall. Verify that the adjustment plates are positioned in between the mounting plate
and the drywall.
8. Once the mounting plate and adjustment plate assembly is in the correct position, bend
the top two flanges of the mud ring upward (approximately 90 degrees)and the bottom
two flanges downward (approximately 90 degrees) to secure them to the rear of the
drywall. Refer to the following illustration.
NOTE:The mounting plate and adjustment plate assembly has a slight amount of
play. This is normal, as it allows for minor adjustments to be made to the
TST-902-DSWduring installation.
