Chapter 5. LEDs Conditions Definition
13
Chapter 5. LEDs Conditions Definition
The LEDs provide useful information about the switch and the status of all individual ports.
[ For GSW-3208M / GSW-3416M / GSW-3424M ]
LED STATUS CONDITION
Power ON Switch is receiving power.
OFF System is booting.
Yellow System is initializing.
System
Green System is running.
ON Port has established a valid link.
Flashing Data packets being received or sent.
Green The connection speed is 1000Mbps.
Link / Act
Yellow The connection speed is 10/100Mbps.
ON The connection is Full Duplex.
FDX/Col.
Flashing Collisions happen for Half Duplex.
