Chapter 6. Manage / Configure the Switch
132
4). MVR Group
After the MVR VLAN is configured, you can assign IP multicast groups (video channels) to the MVR VLAN in “MVR
Group” page. You can assign more than one IP multicast groups (video channels) to one MVR VLAN.
Assigning IP multicast groups to MVR VLAN, you have to select one MVR VLAN first.
For an IP multicast group for MVR VLAN, you have to assign the following settings.
Name – this is the name for this IP multicast group for identification.
Start Address – this is the start IP multicast address for the IP multicast group.
End Address – this is the end IP multicast address for the IP multicast group.
Then click [Apply].
After both MVR VLAN and IP multicast groups are configured, subscribers at the receive ports can receive IP multicast
traffic in the IP multicast groups from source port even they are in difference VLANs.
If you want to remove an IP multicast group, click [Delete]. The IP multicast group will be removed from the list.
Note
: The list does not support edit function. If you want to make any modification, you have to remove it first. Then
create the new one.
