Chapter 6. Manage / Configure the Switch
121
1-5). VLAN Table
This table will show the activity of 802.1Q VLAN. Both static and dynamic 802.1Q VLAN will be shown in the table.
For ports, “S” means static member and “D” means dynamic member.
If GVRP protocol is enabled, this table will also show the learned remote 802.1Q VLAN.
2). Private VLAN
Three kinds of VLAN are defined for this application – Primary VLAN, Community VLAN, and Isolated VLAN.
Community VLAN and Isolated VLAN can communicate with Primary VLAN, but they cannot communicate with each
other. And users in Isolated VLAN cannot communicate with each other. This is a special 802.1Q VLAN
configuration.
2-1). Configuration
