Ex Series Ex450
REF
NO.
PART NUMBER DESCRIPTION QTY
1 CY-1A8170-34700 R4 TIRE KIT,WHEEL L 1
2 CY-1A8170-34710 R4 TIRE 17.5L-24 1
3 CY-1A8170-34730 R4 WHEEL R 1
4 CY-1A8170-34800 R4 TIRE KIT,WHEEL R 1
5 CY-1A8170-34710 R4 TIRE 17.5L-24 1
6 CY-1A8170-34730 R4 WHEEL R 1
7 CY-1A8170-14210 BOLT, HUB M14 16
112
FIG. 61. REAR WHEEL TIRE 3
Copyright 2008 Cub Cadet Yanmar LLC
