REF

NO.

PART NUMBER DESCRIPTION QTY

REF

NO.

PART NUMBER DESCRIPTION QTY

1 CY-129900-07900 Lifter, Engine 1 33 CY-119802-11870 Protector, Nozzle 3

2 CY-26106-080162 Bolt M 8X 16 Plated 2 34 CY-119625-11880 Seat, Nozzle 3

3 CY-129486-07910 Liftings 1 35 CY-129004-11900 Retainer, Nozzle 3

4 CY-26106-080142 Bolt 8X 14 Plated 2 36 CY-120270-54410 Washer 3

5 CY-129004-11241 Shaft Assy, Rocker 1 37 CY-26106-080252 Bolt M 8X 25 Plated 2

6 CY-129004-11251 Shaft, Rocker Arm 1 38 CY-26106-080352 Bolt M 8X 35 Plated 3

8 CY-119802-11260 Support, Rocker Arm 2 39 CY-26106-080502 Bolt M 8X 50 Plated 6

9 CY-119802-11270 Support, Rocker Arm 2 40 CY-129268-11350 Bonnet Assy, Head 1

10 CY-26226-080182 Stud 3 42 CY-129004-03010 Plate, Baffle 1

11 CY-129150-11280 Spring 3 43 CY-129150-03070 Baffle, Breather 1

12 CY-129004-11650 Arm Assy, Rocker 6 44 CY-119802-03110 Plate, Diaphragm 1

13 CY-129150-11230 Screw, Valve 6 45 CY-119802-03121 Cover, Diaphragm 1

15 CY-129150-11750 Nut M8Xp1.0 6 46 CY-119802-03130 Diaphragm 1

16 CY-129150-11370 Cap, Valve 6 47 CY-119802-03141 Spring, Diaphragm 1

17 CY-129008-11700 Head Assy, Cylinder 1 49 CY-129004-11310 Gasket, Bonnet 1

22 CY-27241-400000 Plug 40 2 50 CY-22857-500100 Screw 5X10,Tapping 4

23 CY-129005-11100 Valve, Intake 3 51 CY-22857-500100 Screw 5X10,Tapping 4

24 CY-129100-11112 Valve, Exhaust 3 52 CY-129555-44750 Stud 2

25 CY-129795-11120 Spring, Valve 6 53 CY-49933-000138 Rubber Cap 2

26 CY-129795-11180 Retainer, Spring 6 54 CY-124160-11360 Knob 3

27 CY-121400-11340 Seal, Valve Stem 3 55 CY-24311-000120 O-Ring 1A P 12.0 3

28 CY-124460-11340 Seal, Valve Stem 3 56 CY-119803-77830

Harness,Glow Plug 1

29 CY-27310-080001 Cotter 8 6 57 CY-129008-77800 Plug, Glow 3

31 CY-120130-11860 Guide, Valve 3 58 CY-129008-77820 Connector, Glow Plug 1

32 CY-129150-11810 Guide, Valve 3

FIG. 4. CYLINDER HEAD & BONNET
