Sx Series
Sx3100
Copyright 2010 Cub Cadet Yanmar LLC
REF
NO.
PART NUMBER DESCRIPTION QTY
1 CY-1A6780141102 Shaft,Front Axle 2
2 CY-1A6780141312 Case, Front Bearing 2
3 CY-198165-14140 Packing,Bearing Case 2
4 CY-194151-36670 Plug Pt02 2
5 CY-1E8420-55430 Seal 40X62X14,Oil 2
6 CY-22242-000350 Circlip 35 2
7 CY-24101-060084 Ball Bearing 2
8 CY-24101-062074 Ball Bearing 2
9 CY-26016-080252 Bolt M 8X 25 16
60
FIG. 16. FRONT SPINDLE
