REF
NO.
PART NUMBER DESCRIPTION QTY
1 CY-194300-25180 Sleeve 17X22X12 1
2 CY-168HK1-29220 Shaft, Pump 1
3 CY-168HK0-29230 Ring 23 1
4 CY-168HK0-29251 Valve Plate(P 1
5 CY-168HK1-29450 Spacer 17X22 1
6 CY-168HK0-29600 Block Assy, Cyl 1
7 CY-168HK0-29610 Block, Cylinder 1
8 CY-168HK0-29690 Pin, F2X13.8 6
9 CY-22252-000320 Circlip 32 1
10 CY-168HK0-29620 Plate, Thrust 1
11 CY-22242-000170 Circlip 17 1
104
FIG. 50. PUMP
