REF
NO.
PART NUMBER DESCRIPTION QTY
1 CY-198167-26500 Case,Cmp Seal 1
2 CY-198167-26510 Case,Seal 1
3 CY-198167-26520 Clip 45 1
4 CY-198167-26530 Piston,Inersher 1
5 CY-198167-26540 Brake Case,Inersher 1
6 CY-198167-26550 Plate 1
7 CY-198167-26580 Spring,Brake 1
8 CY-194850-26710 Plate 40, Friction 5
9 CY-194850-26720 Plate 1.2, Steel 6
10 CY-24321-000300 O-Ring G30 1
11 CY-24321-000500 O-Ring 1A G-50.0 1
12 CY-24341-000120 O-Ring 1A S-12.0 1
13 CY-26016-080352 Bolt M 8X 35 3
14 CY-26016-100302 Bolt M10X 30 1
90
FIG. 41. INERTIA BRAKE
