Sx Series
Sx3100
Copyright 2010 Cub Cadet Yanmar LLC
REF
NO.
PART NUMBER DESCRIPTION QTY
1 CY-198220-25130 Spacer 25*33*2 1
2 CY-192167-25310 Circlip,17 1
3 CY-1A7450-25870 Bearing, Tmb005 1
4 CY-1A7530-26050 Shaft Assy, Input 1
5 CY-1A6781-26090 Ball Bearing 6201 1
6 CY-1A7530-26110 Gear, Pto Drive Z=15 1
7 CY-1A7530-26130 Gear, Idle Z=18T 1
8 CY-1E8555-54720 Bearing 2
9 CY-22242-000250 Circlip 25S 1
10 CY-22252-000400 Circlip 40(H) 1
11 CY-24101-062034 Ball Bearing 1
85
FIG. 37. PTO DRIVE SHAFT
